ANTONIO CARRARO
The range of specialized tractors is widening
The new A Series, with 6 models and 48 basic versions, widens Antonio Carraro’s range of specialized tractors for vineyards and orchards.
Reliability and quality are always at the heart of Antonio Carraro’s product offering, and feature in this new range with a design delivering optimal solutions for intended applications. A robust combination, for operators that work in sectors which are often challenging and with increasingly sophisticated equipment, that call for power, hydraulic capacity, excellent handling and comfort.
Powerful yet compact models, designed to reduce the hood height, for easier work under low-hanging branches or between rows.
Power
Engine
Transmission
Weight (KG)
Capacity (KG)
55/ 74.8 kW/hp
F28 DOC DPF - Cylinders/valves 4/ 2 - Stage V - Nm @ rpm 358 @ 1500
Carraro/ T100+30
AV-LB 2680 | AF-B 2740
2600
Size and performance
› The main feature of these two models is in the name: B (low).
› Because of the type of equipment and/or terrain, a great many crops require a low driving position and low centre of gravity. Working under the low-hanging branches and foliage of systems or in tunnels, without damaging the product, or working on steeply sloping terrain are just some of the scenarios that the AV-LB and AF-B have been specifically designed for.
› Numerous application sectors are covered: vineyards, fruit orchards, hazelnut groves, kiwi crops, greenhouses and tunnels.
On flat land and hillsides.
› The AF-B was created as a specific model, with its own characteristics, rather than a design based on the AF-N model.
› With this working approach, it was possible to design adjustable-height mudguards, and focus on the driver’s position, visibility, side guard cleaning and the protective guards.
› Other features that make this product unique are the geometries and performance, appreciated by the sector operators.
FPT F28 engine
Specialist agricultural operators want an ever-better performance which takes into account size constraints. So engines must rise to the challenge of delivering the best performance while guaranteeing compact layouts.
An integrated Egr and smaller Liner Bridge have made it possible to create an extremely compact product. The post-working system, with dimensions reduced to the minimum, guarantees a modular installation, with a single packaging for Stage V.
The FPT F28 engine combines performance with size. The F28 STAGE V is a unique solution, featuring a system that is 5% smaller on average than competitors, to meet demand for high-performance applications.
This new engine has also been chosen for its focus on sustainability, thanks to an optimised combustion efficiency.
